AM3036 is a miniature digitally tunable highpass filter covering the 330 to 700 MHz frequency range. The filter provides 16 selectable highpass cutoff states with 4 digital control bits. The tunable highpass filter can be combined with one of Atlanta Micro’s tunable lowpass filters to provide a flexible tunable bandpass filter solution. AM3036 is packaged in a 4mm QFN package and operates over the -40C to +85C temperature range.
For more information on availability and pricing, please request a quote.
ECCN: EAR99, Harmonized Code: 8525.50.7050
|Function||Cutoff Freq Low (MHz)||Cutoff Freq High (MHz)||Center Freq High (MHz)||Center Freq Low (MHz)||Center Frequency||# in Pack||Bandwidth Low (MHz)||Bandwidth High (MHz)||Insertion Loss (dB)||Typical Rejection (dB)||Package|
|Digitally Tunable Highpass||330||700||1||50||4mm QFN|
