PRODUCT OVERVIEW

AM3032 is a miniature digitally tunable highpass filter covering the 2.5 to 4.5 GHz frequency range. The filter provides 16 selectable highpass cutoff states with 4 digital control bits. The tunable highpass filter can be combined with one of Atlanta Micro’s tunable lowpass filters to provide a flexible tunable bandpass filter solution. AM3032 is packaged in a 4mm QFN package and operates over the -40C to +85C temperature range.

For more information on availability and pricing, please request a quote.



ECCN: 3A001.b.5, Harmonized Code: 8525.50.7050

Data Sheet » S-Parameters »

FunctionCutoff Freq Low (MHz)Cutoff Freq High (MHz)Center Frequency# in PackBandwidth Low (MHz)Bandwidth High (MHz)Insertion Loss (dB)Typical Rejection (dB)Package
Digitally Tunable Highpass250045001504mm QFN
